Wiring Connections
8
4iE
Step 2 - Wiring Connections
Master/relay function: Used to control loads greater than 15A.
Heaters will be split across two 4iE’s, one being the master and
the other being the relay (slave). Only one oor sensor is required,
wired into terminals 1 & 2 of the Master 4iE.
Wiring Connections: Use low voltage electrical cables to link
terminals 2 & 3 of the Master and Relay.
Thermostat Setup: Settings > Adv. settings > Heater setting > Ext
output
NOTE: Set the relay 4iE to relay rst
