1.6 Principal dimensions and weights
1.6.1 Main engines
Figure 1.3 In-line engines (DAAE082421A)
LE4LE2HE3HE4HE2WE1HE1LE1Engine
250367011555002345238525505280Wärtsilä 6L34DF
250514011555002345238525506750Wärtsilä 9L34DF
WeightWE3LE5WE6HE6HE5LE3WE5WE2Engine
33.38805053607101780114514251350Wärtsilä 6L34DF
46.88805053604201780115014251350Wärtsilä 9L34DF
All dimensions are in mm. Weight in metric tons with liquids (wet oil sump) but without flywheel.
Product Guide Wärtsilä 34DF - 3/2012 5
