15.3 Mounting of generating sets
15.3.1 Generator feet design
Figure 15.7 Distance between fixing bolts on generator (DAAE084469)
W 16V34DF Rmax
[mm]
W 12V34DF Rmax
[mm]
W 9L34DF Rmax
[mm]
W 6L34DF Rmax
[mm]H [mm]
---7151400
--8108101600
985985905-1800
10451045980-1950
--1090-2200
B [mm]C [mm]D [mm]E [mm]FG [mm]Engine
170100475Ø35M24 or M2785W L34DF
200130615Ø48M30100W V34DF
138 Product Guide Wärtsilä 34DF - 3/2012
Product Guide
15. Foundation
