19.3 Engine components
Table 19.1 Lubricating oil insert (DAAE083974)
Weight [kg]Dimensions [mm]Engine
BA
105369.4650W 6L34DF
120369.41140W 9L34DF
250479.41338W 12V34DF
250479.41338W 16V34DF
Table 19.2 Charge air cooler insert (DAAE083974)
Weight [kg]Dimensions [mm]Engine
EDC
500436672963W 6L34DF
500594790963W 9L34DF
8506006002056W 12V34DF
9506006002056W 16V34DF
Table 19.3 Turbocharger (DAAE083974)
Weight (kg)Dimensions [mm]Engine
KHGF
7737668616631017W 6L34DF
7837668616631017W 9L34DF
2 x 7737668616631017W 12V34DF
2 x 7837668616631017W 16V34DF
164 Product Guide Wärtsilä 34DF - 3/2012
Product Guide
19. Transport Dimensions and Weights
