Figure 19.4 Major spare parts (DAAE083973)
Weight [kg]DescriptionItem NoWeight [kg]DescriptionItem no
11.5Starting valve9153.5Connecting rod1
8.5Main bearing shell1074Piston2
127Split gear wheel11253Cylinder liner3
31Small intermediate gear12410Cylinder head4
156Large intermediate gear133Inlet valve5
103Camshaft gear wheel142.8Exhaust valve6
1.5Piston ring set1537Injection pump7
0.5Piston ring15.5Injection valve8
Product Guide Wärtsilä 34DF - 3/2012 165
Product Guide
19. Transport Dimensions and Weights
