Wascom EMERALD W75ES - Machine Does Not Extract; Motor Not Operating at Wash Speed

57
Trouble shooting
86
1210
87
1211
A
A
B
C
If machine does not extract
A Check the extract relay and relay coil for
proper operation.
B Check the door lock, including cable.
If motor does not operate at wash speed
A Check the wash relay.
B Check the normally-closed contact of extract
relay.
C Check the motor and V-belt.
D Review procedures outlined under section "If
machine does not start" above.
Fig.
86
Fig.
87
