Technical data
3
Technical data W105ES EMERALD SERIES
Dry load capacity up to 25 lbs
Overall dimensions Width 660 mm 26 in
Depth 795 mm 31 5/16 in
Height 1050 mm 41 11/32 in
Net weight 147 kg 323 lbs
Dyn force 1.7 ±3.4 kN 408±816 lbs. force
Crated dimensions Volume 0.65 m
3
23.0 cu.ft.
Weight 158 kg 348 lbs
Inner drum Diameter 520 mm 20 1/2 in
Depth 473 mm 18 5/8 in
Volume 100 litre 3.6 cu.ft
Speed of rotation Wash 54 r.p.m.
Extraction 543 r.p.m.
G-factor During wash 0.8
During extraction 90
Motor speed During wash 344 r.p.m.
During extraction 3514 r.p.m.
Voltage requirements Choice:
120 V 1-phase 60 Hz
or
208-240 V 3-Phase 60 Hz
Rated output power Motor, wash 3-phase 150 W
0.2 HP
Motor, extract. 3-phase 900 W
1.2 HP
Motor, wash 1-phase 140 W
0.18 HP
Motor, extract. 1-phase 550 W
0.75 HP
Overcurrent protection Three-phase 15 A
Single-phase 20 A
Water connections
Recommended water pressure 2-6 kp/cm
2
25-85 psi
Hose connection, water 20 DN 3/4" in
Hose connection, drain 74 mm 3" in
