Solenoid Valve
Part Number
600 30289
Function
Controls flow of water into the machine during filling of the tank and
final rinsing.
Description
Electromagnetically operating water valve for use with cold and hot water.
Type Burkert 6213
Body material: DR Brass Duty cycle: continuous
Seal material: EPDM Ambient temperature: Max. +55°C
Media: Oil, fat-free fluids Pressure: 0 - 10 Bar
Voltage: 230 V Flow rate: 1.9m³/h (at1bar)
Frequency: 50 Hz Media temperature: -30 to +120°C
Power: 8 W Construction: IP65
Diagram
Replacement
Solenoid coil
Release electrical connector fixing screw and detach electrical connector from
solenoid coil. Unscrew fastening nut on top of solenoid coil and slide up solenoid
coil off solenoid body. Replace in reverse order.
Solenoid body
See assembly drawing in the Assembly Diagrams section.
Adjustment
There is no adjustments are required.
