Washtech PW2 - Control Panel Assembly

EXPOLODED PERSPECTIVE
Parts List
QTYDESCRIPTION
PART NUMBERITEM
2
TEMP GAUGE RECTANGULAR 58x25
600 900801
1LENS & NEON ASSY (RED) 12mm600 301612
1LENS & NEON ASSY (GREEN) 12mm600 301633
2LENS & NEON ASSY (AMBER) 12mm600 301624
1
M2 - AL CONTROL LABEL
400 700795
1
SWITCH 4 WAY QUICK CONNECT
600 302696
1KNOB 4 POSITION30415
7
1M2 THROUGH TO PW3 CONTROL PANEL SUB-ASSY 400 101408
1BUTTON ROLD "START" PRINTED600 302449
1
SWITCH START ROLD-SP MOMENTARY
600 3010110
400 10139
5/07/2009
3-D
AL8(M)/PW CONTROL PANEL ASSEMBLY
REV
5
3
4
4
2
1
1
6
7
8
9
10
Service Manual PW2(W)
23
Revision 1B
