Installation
WARNING
Installer must be suitably qualified and ensure compliance with all codes and
standards including AS/NZS3500.1.
Failure to comply even partially with installation instructions may void the
warranty.
Positioning
Unpack machine, check for damage and complete delivery. Install machine on
sound waterproof self-draining floor and use adjustable feet to level machine.
Allow room for detergent to one side of machine or in adjacent cupboard. 20litre
container requires about 450H x 250W x 350D, but smaller containers are available
from many suppliers.
Benchwork
Refer to the installation diagram. Recommended bench depth is 850 mm, height
900 mm. We recommend sink smaller than rack with guide to prevent rack falling
into sink. Align sink with dishrack path as shown on the installation diagram.
Water Supply
Hot water temperature 65°C ± 5°C
Connection 20 mm (3/4" BSP Male)
Flow rate minimum 20 litres per minute
Consumption per cycle 4 litres approximately
Backflow prevention Dual Check Valve fitted standard
Pressure 200-350 KPa = 30-50 Psi.
Above this range fit pressure limiter. Don’t use small diameter plastic supply lines.
FLUSH supply line before connection. Poor quality supply or excessive water
hardness may affect performance or damage machine – filtration and/or softening
is recommended.
Waste
40 mm gravity drain – refer point B on installation diagram – run waste directly
behind the machine.
Power
Machine requires 3 Phase, Neutral and Earth, 415V, 50Hz, 18kW, 27A/ph,
permanently wired via wall switch mounted adjacent to machine. Wash pump
rotation must be checked after installation to ensure correct direction (excessive
noise and damage with incorrect direction).
Detergent
Insert detergent pump inlet hose into container of commercial low foam detergent.
Open machine door and switch machine on. Press and hold detergent prime
switch behind front cover until chemical flows into machine.
Commercial detergents can be hazardous – read instructions and handle with care.
Installation Checklist
Complete attached Installation Checklist to ensure machine is installed and
running correctly, and operator is familiar with operating procedures.
Troubleshooting
If the machine doesn’t fill after switching on the power, check and ensure that the
hot water supply tap is open, water supply pressure is not below specification and
Dual Check Valve is correctly installed (arrows on the dual check valve’s body
specify water flow direction).
