WaterLogic WL Cube - Page 54

No Part No. Description WLUSA Part No.
1 PL-1389 Left Side Panel NA
2 FW-0005-L00-00 Spout, Mirror, No Gauze – 18 mm NA
3 FU-0012 UVC Sensor Fixing Metal Bracket NA
4 PL-1391 Front Frame Panel NA
5 PL-1390 Front Cover NA
6 PL-1395 Spout Assembly Bracket with BioCote® NA
7 PL-1392 Drip Tray Body with BioCote® NA
8 PL-1393 Drip Tray Grill with BioCote® NA
9 ST-8350 Rubber Feet NA
10 PL-1387 Base Plate NA
11 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
12 PL-1311 Leak Detection Sensor Bracket PL-1311
13 ST-8207-CN Leak Containment Tray Clip – Sensor 0.5 mm 12-3180
14 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
15 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
16 CT-2093 Cold Tank 1.4 Liter NA
17 CO-9001-A Compressor 10-2200
18 CO-9008 Domestic Filter Dryer 12-1001
19 PL-1388 Side Panel – Right NA
20 NA Bulkhead Fitting ¼” x ¼” (ST) NA
21 EL-5029 Socket for Plug Connection 19-1090
22 NA AC Power Fuse Holder with Fuse NA
23 EL-5004 Red Power Switch 10-3008
24 EL-5005 Green Heater / Compressor Switch 10-3009
25 CO-9050 Cooling Wire Condenser NA
26 EL-5027 Micro Door Lock S/W Only NA
27 PL-1396 Micro Switch Cover NA
28 PL-1386 Back Panel NA
29 CT-2094 Fan Motor – DC 24V NA
30, 31
NA
Hot and Cold Tank Drain Valve (consists of P/N’s CT-2031 Drain Body
Valve 5/16” and CT-2025 Drain Valve Cap 5/16” – ¼”)
14-5011
32 FU-0012 UCV Sensor Fixing Metal Bracket NA
33 PL-1383 Top Cover NA
34 NA 5/16” – ¼” Reducing Straight Connector NA
35 FT-0008-L00-00 Filter Bracket NA
CUBE Operating, Installation, and Service Manual Page 54 - Revision: 6-23-2015
