WaterLogic WL Cube - Page 55

36 FT-0004-L00-WLT CBC 10” 1 Micron Filter Assembly NA
37 PU-4017-B Hot and Cold Solenoid Valve PU-4017-B
38 NA Equal Tee Connector ¼” ST NA
39 EN-0008-L01-00 Electronic Ballast 15W 120V/60 Hz NA
40 EL-0016-L00-00 Power Transformer 120v / 2A NA
41 PL-1384 Electronics Cover NA
42 LP-7326 UI Label with Waterlogic Logo NA
43 EN-6140-L00-00 PCB – UVC EN-6140-L00-00
44 PL-1394 PCB Fixing Frame NA
45 EN-6141 Key and Display PCB NA
46 PL-1385 Upper Shelf NA
47 PL-1397 Silicon Tubing Guide A NA
48 PU-4064 Silicon Tube 5/16" for Hot Water 10-7040
49 PL-1398 Silicon Tubing Guide B NA
50 HT-0001-I00 Hot Tank 1.3 Liters 500 Watts - 189°F (87°C) NA
Not
Shown
EL-5001-A Power Cord 10-3007
CUBE Operating, Installation, and Service Manual Page 55 - Revision: 6-23-2015
