CUBE PARTS LIST
No Part No Description WLUSA Part No.
1 PU-4028 Bulkhead Connector Union ¼” * ¼” JG (PI1208S) 10-3067
2 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
3 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
4 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
5 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
6 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
7 PU-4031-B Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
8 NA 5/16” – ¼” Reducing Straight Connector NA
9 FT-0004-L00-WLT CICO CBC 1 Micron 10” Filter Assembly NA
10 NA 5/16” – ¼” Reducing Straight Connector NA
11 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
12 NA Equal Tee Connector ¼” JG NA
13 PU-4017-B Hot and Cold Solenoid Valve 24V- 300mm PU-4017-B
14 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
15 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
16 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
17 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
18 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
19 CT-2093 Cold Tank 1.4 Liter NA
20 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
21 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
22 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
23 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
24 PU-4017-B Hot and Cold Solenoid Valve 24V- 300mm PU-4017-B
25 NA Equal Tee Connector ¼” JG NA
26 PU-4064 Silicon Tube 5/16" for Hot Water 10-7040
27 PU-4064 Silicon Tube 5/16" for Hot Water 10-7040
28 FW-0005-L00-00 Firewall Housing NA
29 FW-0008-L00-00 Firewall Quartz Spiral NA
30 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
31 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
32 PU-4031-B Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
33 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
34 HT-0001-I00 Hot Tank 1.3 Liters 500 Watts 189°F (87°C) NA
CUBE Operating, Installation, and Service Manual Page 57 - Revision: 6-23-2015
