WaterLogic WL Cube - Page 58

35 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
36 PU-4014 Tube - Blue 8mm - 5/16” JG (PE-0806-100M-B) 10-3062
37 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
38, 39 NA
Hot and Cold Tank Drain Valve (consists of P/N’s CT-2031 Drain Body
Valve 5/16” and CT-2028 Drain Valve Cap 5/16”)
14-5011
40 PU-4066 Stem Elbow Connector ¼” * ¼” JG (PI220808S) NA
41 PU-4164 Solenoid Valve 24 DC (Single Spring Load) NA
42 PU-4008 Equal Elbow Connector ¼” JG (PI0308S) NA
43 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
44 NA Equal Tee Connector ¼” JG NA
45 PU-4031 Tube - Blue O.D. ¼” JG (PE-08-BI-1000F-B) NA
Not
Shown
CT-2029 UV Sensor CT-2029
Not
Shown
CT-2090-A UV Lamp 10-8075
Not
Shown
NA Cold Probe NA
CUBE Operating, Installation, and Service Manual Page 58 - Revision: 6-23-2015
