WaterLogic WL2FLT - ELECTRICAL SPECIFICATIONS

WL2FLT Manual Page 10 – Revision 10-26-2021
SHIPPING SPECIFICATIONS
ITEM
WL2FLT
Width/Depth/Height
349mm x 363mm x 1176mm
13.74” x 14.29 x 46.30”
Weight (dry) Unit Only
33.0 kg (72.8 pounds)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
120V/60Hz
15 Amp Service
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Heater
500
4.2 Amps
Compressor
168
1.4 Amps
UV Lamp System
36
0.3Amps
WL2FLT TOTAL
706
5.9 Amps
46.30”
14.29”
13.74”
