Tip: To prevent band spreading, ensure that the tubing is fully bottomed in the connection port
before you tighten the compression screw.
First use tightening
Reinstalled
Short flats
Compression screw
2-piece stainless steel ferrule
Tighten the fitting finger-tight plus as much as an additional 1/6-turn using a 1/4-inch open-end
wrench.
Reinstalled tightening
