3-4 Maintenance Procedures
Cleaning the mass spectrometer sample cone
For details about how to clean the sample cone, refer to the mass
spectrometer’s operator’s overview and maintenance guide.
Cleaning or replacing the corona pin
APGC ion chamber assembly:
APGC ion chamber body
Insulator
Spring
Corona discharge pin
Ceramic washer
Corona pin adjuster nut
