What to do if Waters Security Sensors shutter failed to home?
If the Waters Security Sensors shutter failed to home, flush the flow cell, establish flow, and reset communications from the control panel or console. If the problem continues, contact Waters Technical Service.
What to do if Waters Security Sensors Ethernet cable disconnected?
If the Ethernet cable is disconnected from Waters Security Sensors, connect (or reconnect) the Ethernet cable and reset communications from the control panel or console.
What to do if Waters Security Sensors lamp lighting failure?
If the Waters Security Sensors experiences a lamp lighting failure, cycle power to the detector. Check the lamp power connection. If the issue persists, replace the lamp.
What to do if Waters Security Sensors lamp failure?
If the Waters Security Sensors indicates a lamp failure, check the lamp icon, cycle power to the detector, and then replace the lamp.
What to do if Waters Security Sensors shutter failure message?
If the Waters Security Sensors displays a shutter failure message, clear bubbles from the flow cell and power off and then power on the PDA detector.
How to fix Waters Security Sensors detector not responding?
Inspect cable connections, tighten connectors, or replace cable if the Waters Security Sensors detector is not responding to the ACQUITY UPLC Console due to a bad or disconnected cable.
How to fix Waters Security Sensors energy level too low?
If the Waters Security Sensors energy level is too low, clear the flow cell and establish flow. If the problem persists, replace the lamp. If the issue continues, contact Waters Technical Service.
What to do if Waters Security Sensors wavelength outside of allowed range?
If the Waters Security Sensors wavelength is outside of the allowed range, modify the instrument method, ensuring the wavelength end is lower than 500 nm.
What to do if Waters Security Sensors Delta between previous and current timestamp is incorrect?
If the delta between the previous and current timestamp is incorrect on the Waters Security Sensors, cycle power to the detector. If the error persists, contact Waters Technical Service to replace the personality card.
What to do if Waters Security Sensors thermal controller disabled?
If the thermal controller is disabled on your Waters Security Sensors, cycle power to the detector. If the problem persists, contact Waters Technical Service.
Provides an overview of ACQUITY UPLC column compartments and maintenance procedures.
Lists critical safety warnings related to column compartment usage, including solvent autoignition and hazardous materials.
Lists the different types of ACQUITY UPLC column compartments available for use.
Details the standard ACQUITY UPLC column heater (CH-A), its temperature range, and features.
Identifies and describes the key components within the column heater assembly.
Details the components of the Column Manager (CM-A) and Auxiliary Column Manager (CM-Aux).
Explains configurations using CM-Aux modules for expanded column capacity.
Describes the features of the 30-cm column heater/cooler, including column capacity and mounting.
Provides guidelines for correctly installing fittings to prevent bandspreading and ensure proper connections.
Details the process for installing an MS extension bracket to position the column heater for mass spec applications.
Details on connecting the necessary tubing for column manager and auxiliary manager modules.
Guide to setting up a single-stack system with one CM-Aux module for up to four columns.
Steps to rearrange instruments within the system stack for a new configuration.
General steps to establish a multiple-stack configuration using two CM-Aux modules.
Guidance on selecting a system module configuration based on instrument identification.
Steps to exchange the switching-valve cartridges for the CM-A module.
Instructions for installing compartment diagrams onto module doors.
General steps and considerations for installing system tubing connections.
Diagram and notes for a four-column setup with the inlet valve on the right.
Diagram and notes for a four-column setup with the inlet valve on the left.
Diagram and notes for a six-column setup with the inlet valve on the left.
Tables detailing tubing part numbers and lengths for four and six column configurations.
Instructions for assembling new fittings, including marking compression screws and fitting bodies.
Steps to configure the system for a four-column setup using the ACQUITY UPLC Console.
Steps to configure the system for a six-column setup using the ACQUITY UPLC Console.
Details on configuring a four-column setup using 50mm columns and CM-Aux modules.
Explains how to use advanced mode for direct control of valves in the CM-A.
Describes the meaning of the Power LED indicator on CM-A and CM-Aux modules.
Explains the Run LED indicator, showing when the instrument is operating or idle.
Instructions on closing and securing the column compartment door, ensuring proper seal alignment.
Describes the column manager control panel interface for monitoring and setting column temperature and selection.
Procedures for identifying and resolving leaks detected by column compartment sensors.
Overview of routine maintenance tasks recommended for column compartments.
Information on how and when to contact Waters Technical Service for support.
Important safety and handling advisories to observe during maintenance operations.
How to set up maintenance counters and warnings for proactive component management.
Information that only Waters Technical Service should replace the 30-cm column heater's leak sensor.
Procedure for replacing the leak sensor in column manager or auxiliary column manager modules.
Provides an overview of ACQUITY UPLC column compartments and maintenance procedures.
Lists critical safety warnings related to column compartment usage, including solvent autoignition and hazardous materials.
Lists the different types of ACQUITY UPLC column compartments available for use.
Details the standard ACQUITY UPLC column heater (CH-A), its temperature range, and features.
Identifies and describes the key components within the column heater assembly.
Details the components of the Column Manager (CM-A) and Auxiliary Column Manager (CM-Aux).
Explains configurations using CM-Aux modules for expanded column capacity.
Describes the features of the 30-cm column heater/cooler, including column capacity and mounting.
Provides guidelines for correctly installing fittings to prevent bandspreading and ensure proper connections.
Details the process for installing an MS extension bracket to position the column heater for mass spec applications.
Details on connecting the necessary tubing for column manager and auxiliary manager modules.
Guide to setting up a single-stack system with one CM-Aux module for up to four columns.
Steps to rearrange instruments within the system stack for a new configuration.
General steps to establish a multiple-stack configuration using two CM-Aux modules.
Guidance on selecting a system module configuration based on instrument identification.
Steps to exchange the switching-valve cartridges for the CM-A module.
Instructions for installing compartment diagrams onto module doors.
General steps and considerations for installing system tubing connections.
Diagram and notes for a four-column setup with the inlet valve on the right.
Diagram and notes for a four-column setup with the inlet valve on the left.
Diagram and notes for a six-column setup with the inlet valve on the left.
Tables detailing tubing part numbers and lengths for four and six column configurations.
Instructions for assembling new fittings, including marking compression screws and fitting bodies.
Steps to configure the system for a four-column setup using the ACQUITY UPLC Console.
Steps to configure the system for a six-column setup using the ACQUITY UPLC Console.
Details on configuring a four-column setup using 50mm columns and CM-Aux modules.
Explains how to use advanced mode for direct control of valves in the CM-A.
Describes the meaning of the Power LED indicator on CM-A and CM-Aux modules.
Explains the Run LED indicator, showing when the instrument is operating or idle.
Instructions on closing and securing the column compartment door, ensuring proper seal alignment.
Describes the column manager control panel interface for monitoring and setting column temperature and selection.
Procedures for identifying and resolving leaks detected by column compartment sensors.
Overview of routine maintenance tasks recommended for column compartments.
Information on how and when to contact Waters Technical Service for support.
Important safety and handling advisories to observe during maintenance operations.
How to set up maintenance counters and warnings for proactive component management.
Information that only Waters Technical Service should replace the 30-cm column heater's leak sensor.
Procedure for replacing the leak sensor in column manager or auxiliary column manager modules.
General| Technology | Ultra Performance Liquid Chromatography (UPLC) |
|---|---|
| Flow Rate Range | 0.001 to 2.000 mL/min |
| Maximum Pressure | 15, 000 psi (1, 034 bar) |
| Temperature Range | 4 °C to 65 °C |
| Data Sampling Rate | up to 80 Hz |
| Detector Options | Photodiode Array (PDA), UV/Vis, Fluorescence, Evaporative Light Scattering |
| Detection Wavelength Range | 190 to 800 nm |
| Column Compatibility | UPLC Columns (1.7 μm particle size) |
