Waters ACQUITY UPLC - Replacing the Column

Maintaining the column compartments 121
6. Align the leak sensor’s T-bar with the slot in the side of the leak sensor
reservoir, and slide the leak sensor into place.
TP02892
Slot in leak
sensor reservoir
T-bar
Leak sensor
installed in
reservoir
