Preparing the column compartments 53
Plumbing the CM-A and CM-Aux
Tip: To avoid damaging the tubing and column compartment cover latches,
ensure the tubing is routed through the grooves in the sides, top, and bottom
of the column compartment.
Location of grooves in sides, top, and bottom of column compartment:
To plumb and configure the CM-A and CM-Aux, consult these pages:
• For tubing connection and fittings information, see page 68, page 76,
and page 77.
• For information about configuring the new column configuration in the
software, see page 78.
• For column installation information, see page 81.
Grooves(3) on right side
and top of column
compartment
Location of grooves (3) on
left side and bottom of
column compartment
