Using the column compartments 109
9. Align the leak sensor’s T-bar with the slot in the side of the leak sensor
reservoir, and slide the leak sensor into place.
10. Reattach the connector to the receptacle on the front of the instrument,
and power-on the column manager.
Slot in leak
sensor reservoir
T-bar
Leak sensor
installed in
reservoir
Leak sensor
connector
receptacle
