39 PB0347:m-620atex-en-03
22 Dimensions
A 303mm (11.93″) H 94mm (3.70″)
B 220mm (8.66″) I 189mm (7.44″)
C 115° J 125mm (4.92″)
D 250mm (9.84″) K 62mm (2.44″)
E 115mm (4.53″) L 50mm (1.97″)
F 137mm (5.39″) M 65mm (2.56″)
G 147mm (5.79″) N 115mm (4.53″)
23 Replacements
Spares and replacements should be ordered through Watson-Marlow pumps or through an official
representative. Only Watson-Marlow spares and replacements should be used in order to guarantee
continued compliance with the ATEX directive.
Watson-Marlow’s policy is to provide spare parts for all products for a minimum of 7 years from
discontinuation. The ability to implement this policy is not entirely within Watson-Marlow’s control and
cannot be guaranteed, but every effort willbe made to honour this policy.
Please contact your local Watson-Marlow representative for assistance.
