Watson-Marlow 620RA - Performance Data

24 Performance data
Note: Flow rates quoted have been rounded for simplicity, but are accurate to within 5% -well within the
normal tubing-tolerance variation of flow rate. They should therefore be taken as a guide. Real flow
rates in any application must be determined empirically.
Note: Two standard speed ranges are available as shown in the tables below. Other speed ranges are
available from applications engineering, email: applications@wmftg.co.uk
620 Neoprene, GORE® STA-PURE® Pump Tubing (l/min)
Pumphead 620RA
Min Max Ratio Speed range 6.4mm 9.6mm 12.7mm 15.9mm
8 76 10:1 8 to 76rpm 0.10-0.9 0.20-1.9 0.32-3.0 0.49-4.6
16 165 10:1 16 to 165rpm 0.19-2.0 0.40-4.1 0.64-6.6 0.98-10
26 265 10:1 26 to 265rpm 0.31-3.2 0.65-6.6 1.0-11 1.6-16
Pumphead 620REA 620RE4A
Min Max Ratio Speed range 12.0mm 17.0mm 12.0mm 17.0mm
8 76 10:1 8 to 76rpm 0.32-3.0 0.58-5.5 0.27-2.6 0.40-3.8
16 165 10:1 16 to 165rpm 0.64-6.6 1.2-12 0.54-5.6 0.81-8.3
26 265 10:1 26 to 265rpm 1.0-11 1.9-19 0.88-9.0 1.3-13
PB0347:m-620atex-en-03 40
