41 PB0347:m-620atex-en-03
620 Neoprene, GORE® STA-PURE® Pump Tubing (USGPM)
Pumphead 620RA
Min Max Ratio Speed range 6.4mm 9.6mm 12.7mm 15.9mm
8 76 10:1 8 to 76rpm 0.03-0.2 0.05-0.5 0.08-0.8 0.13-1.2
16 165 10:1 16 to 165rpm 0.05-0.5 0.11-1.1 0.17-1.7 0.26-2.7
26 265 10:1 26 to 265rpm 0.08-0.8 0.17-1.8 0.27-2.8 0.42-4.3
Pumphead 620REA 620RE4A
Min Max Ratio Speed range 12.0mm 17.0mm 12.0mm 17.0mm
8 76 10:1 8 to 76rpm 0.08-0.8 0.15-1.4 0.07-0.7 0.11-1.0
16 165 10:1 16 to 165rpm 0.17-1.7 0.31-3.1 0.14-1.5 0.21-2.2
26 265 10:1 26 to 265rpm 0.27-2.8 0.50-5.1 0.23-2.4 0.35-3.5
