620 Marprene/Bioprene (l/min)
Pumphead 620RA (TL tubing)
Min Max Ratio Speed range 6.4mm 9.6mm 12.7mm 15.9mm
8 76 10:1 8 to 76rpm 0.10-1.0 0.20-1.9 0.32-3.0 0.42-4.2
16 165 10:1 16 to 165rpm 0.21-2.1 0.40-4.1 0.64-6.6 0.85-8.6
26 265 10:1 26 to 265rpm 0.34-3.4 0.65-6.6 1.0-11 1.4-12
Pumphead 620REA (TL tubing) 620REA (TM tubing)
Min Max Ratio Speed range 12.0mm 17.0mm 12.0mm 17.0mm
8 76 10:1 8 to 76rpm 0.30-2.8 0.54-5.1 0.30-2.8 0.47-4.5
16 165 10:1 16 to 165rpm 0.59-6.1 1.1-11 0.59-6.1 0.94-9.7
26 265 10:1 26 to 265rpm 0.96-9.8 1.7-18 0.96-9.8 1.5-16
Pumphead 620RE4A (TL tubing) 620RE4A (TM tubing)
Min Max Ratio Speed range 12.0mm 17.0mm 12.0mm 17.0mm
8 76 10:1 8 to 76rpm 0.25-2.4 0.38-3.6 0.25-2.4 0.33-3.1
16 165 10:1 16 to 165rpm 0.50-5.2 0.75-7.8 0.50-5.2 0.66-6.8
26 265 10:1 26 to 265rpm 0.82-8.3 1.2-12 0.82-8.3 1.1-11
PB0347:m-620atex-en-03 42
