10 TECHNICAL SPECIFICATIONS
Measurement Functions
Measurement field probes Interchangeable; automatic probe detection and recognition system
Measurement units V/m, kV/m, uW/cm2, mW/cm2, W/m2, uT, T, % (depending on probe)
Acquisition time 2 samples per second
Result types Actual total field value, axis field value (X, Y, Z), maximum and minimum
Average type Sliding average (continuous), arithmetic average, normative average
Averaging time 10s, 30s, 1min, 2min, 5min, 6min, 10min, 15min, 30min
Alarm audible signal, 2400 Hz; adjustable threshold
Memory
Sample acquisition adjustable period 1s, 5s, 10s, 30s, 1min, 5min
Capacity
62,400 samples (with GPS data)
27,300 samples (without GPS data)
Up to 100 registers
Interfaces
Probe Push-pull connector. Automatic detection and recognition
Data download Mini USB connector
Firmware update Mini USB connector
Battery charger coaxial jack connector + LED
Display
Display type Transmissive, monochrome, STN, negative
Display size 60 x 78 mm (240 x 320 pixels)
Backlight White LED
Display range 5 digits: 0.0001 to 99999
GPS
General
SiRFstarIII, 12 channels, embedded
Chip set SiRF starIII GSC3
Position accuracy 1.5 m (CEP50) , 1.8 m (CEP95)
Sensitivity -157 dBm (tracking)
SBAS (Satellite Based Augmentation System) WAAS/EGNOS/MSAS support
Geodetic system WGS 84
General Specifications
Battery rechargeable Li-ion battery
Operation time > 10 hours (GPS enabled) > 14 hours (GPS disabled) (backlight level 3)
Standby time > 3 years
Recharge time 4 – 5 hours
Temperature range -10 ºC a +45 ºC
Size (without field probe) 100 x 215 x 40 mm
Weight (without probe) 490 g (including the internal GPS receiver)
Accessories
Hardcase, battery charger, USB-mini USB cable, SMP Reader software, user
manual, probe calibration certificate
- 29 -
