Wavetronix SmartSensor Matrix - Introduction to SmartSensor Matrix

In this chapter
 SmartSensor Matrix Package
 Selecting a Mounting Location
e Wavetronix SmartSensor Matrix™ is a stop bar presence detector designed for use at
signalized intersections (see Figure I.1). e SmartSensor Matrix detects vehicles through
the use of a 24.125 GHz (K band) operating radio frequency. Using what is classied as
frequency modulated continuous wave (FMCW) radar, SmartSensor Matrix detects and
reports vehicle presence in as many as 10 lanes simultaneously.
Figure I.1 – Wavetronix SmartSensor Matrix
SmartSensor Matrix is a rst-of-its-kind radar stop bar detector with Radar Vision™. It
delivers the reliability of radar and the simplicity of non-intrusive detection for stop bar
presence detection. In many situations, the sensor is installed on the roadside in order to
prevent the need for lane closures and trac control. Once the unit is installed, the congu-
Introduction
