Vehicle detections are represented by tracks (a series of dots) along the sensor’s view. e
vehicle tracks show where the sensor is detecting trac and will later help you congure
lanes. Vehicle track history can be cleared from the screen by clicking the Clear Tracks but-
ton below the sensor view.
Note
Vehicle tracks are not constrained to lanes, even after you have saved a lane configu-
ration to the sensor.
Display Options
e Lanes & Stop Bar tab has the following display options:
 Edit Area
 Edit Area with Saved Conguration Overlay
 Edit Area with Automatic Conguration Overlay
Edit Area
e edit area is where manual changes to the sensor’s conguration are made (see Figure
7.2). e changes you make in the edit area will only be saved if you click on the Save Con-
g button or click on another tab.
Edit Area
Figure 7.2 – Edit Area
You can copy elements from the saved and automatic conguration, which will be described
later.
