72 CHAPTER 7  LANES & STOP BARS
Saving the Configuration
Aer automatic and manual conguration is complete, click the Save Cong button to save
the changes to the sensor. If you attempt to leave the Lanes & Stop Bar view before saving
your changes, the following prompt will appear (see Figure 7.8).
Figure 7.8 – Save Changes Dialog
Moving the Sensor View
e SSMM soware shows the position of the SmartSensor Matrix and the view is drawn
from the perspective of the sensor. e sensor’s default position is in the bottom-le corner
of the display. If the perspective in the soware does not match your perspective of the
roadway, click the Rotate View button until the sensor position matches the approach you
are conguring.
Note
Moving the sensor in the software will have no eect on the sensor’s performance.
Its purpose is to facilitate the configuration process.
Restarting Auto Lane Config/Rebooting the Sensor
Restarting the automatic lane conguration will erase any auto-conguration information
that may have been gathered and will start the auto-conguration process over again.
Rebooting the sensor will also erase any auto-conguration information, but in addition
will clear and recongure the sensor thresholds.
Follow the steps below to restart the automatic lane conguration process or reboot the
sensor:
1 Click the Restart/Reboot button and the Restart or Reboot window will appear (see
Figure 7.9).
2 Select the appropriate radio button and click OK.
