1.1 Transmitter module 2.4 Dual FHSS
12 channels
Transmission: adaptive frequency hopping spread spectrum
Frequency range: 2,401 – 2,4835 GHz
Power output: 20 dBm (100 mW)
Functions (channels): 12
Frequencies: 81, France: 52
Intervall: 10 ms
Modulation: Quadrature Phaseshift keying
Back channel for telemetry and sensor data
Real time data via earplug, LED or via PC (GIGAControl)
Receive sensitivity: -84 dBm
Temperature range: -10°C to +60 °C
Voltage: 5 - 10 Volt
Current consumption: 200 mA
Range: > 3000 m
Resolution of channels: 4096 steps
Data storing: Micro SD card
Software: GIGAControl
Firmware update: Micro SD card
Antennas: 2 patch areals
Polarisation: circular
Dimensions : 95 x 65 x 18 mm
Weight: 60 g
1.2 Dual Receiver 2.4 Dual FHSS micro
8/10/12
Double receiver circuit
Transmission: adaptive frequency hopping spread spectrum
Frequency range: 2,401 – 2,4835 GHz
Power output: 20 dBm (100 mW)
Functions (channels): 12
Frequencies: 81, France: 52
Intervall: 10 ms
Modulation: Quadrature Phaseshift keying
Back channel for telemetry and sensor data
Receive sensitivity: -100 dBm
Temperature range: -10°C to +60 °C
Frequency range: 2,401 – 2,4835 GHz
Power output: 20 dBm (100 mW)
Functions (channels): 12
Frequencies: 81, France: 52
Interval: 10 ms
Modulation: QPSK*
Back channel for telemetry and sensor data
Real time data via earplug, LED or via PC (GIGAControl)
Receive sensitivity: -84 dBm
Current consumption: 130 mA
Resolution of channels: 4096 steps
Firmware update: USB adapter
Antennas: 2 λ/4 wires
Polarisation: linear
Antenna length: 200 mm
Antenna length in operation: 29 mm
Dimensions: 55 x 33 x19 mm
Weight: 30 g
* Quadrature Phaseshift keying
1.3 Dual Receiver 2.4 Dual FHSS 12-22 R
Two separate receivers
Transmission: adaptive frequency hopping spread spectrum
(adaptive FHSS)
Frequency range: 2,401 - 2,4835 GHz
Transmitting power: 20 dBm (100 mW)
Functions (channels): 12
Frequencies: 81, France: 52
Intervall: 10 ms
channels width: >= 1 MHz
Modulation: QPSK*
Reverse channel for telemetry and sensor data
Free allocation of 22/30 servo exits to 12 (16) channels
Free programming of servo exits
Servo failsafe
Channel failsafe
Servoline: max. 31 points
Mixing function - five mixers per servo exit
Sequencer function
Slow function
Automatic Servo synchronisation - max 8 servos per channel
Temperature range: -10°C to +60 °C
Operation voltage: 5 - 10 Volt
Power consumption: 200 mA
Range: > 3000 m
Resolution: 4096 steps
Data storing: Micro SD card
Operation software: GigaControl
Servoa exits: 22, max. 8 servos per channel
Electronic switch board , battery testing function
Data storage: Micro SD card
Double power supply: two six cells NiMH batteries (min SUB
C-Größe) or two two cells Lithium-Polymer batteries or two
three cells A123 batteries
2 λ/4 radiators
Polarisation: linear
Antenna total length: 200 mm, operational length: 29 mm
Dimensions: 143 x 84 x 26 mm
Weight: 272 g, switch board with cable 34 g, areals: each 4 g
* Quadrature Phase shift keying
1.4 Dual Receiver 2.4 Dual FHSS 12-22 R Gyro II
like above plus:
SMM gyros on X and Y axis, normal mode and heading lock mode
adjustable
1.5 Dual Receiver 2.4 Dual FHSS 12-22 R Gyro III
like above plus:
SMM gyros on X, Y and Z axis, normal mode and heading lock
mode adjustable
1.6 Dual Receiver 2.4 Dual FHSS 12-22 R Gyro III + GPS
like above plus:
GPS data logging
1.7 Dual Receiver 2.4 Dual FHSS 12-30 R Gyro III + GPS
like above plus:
30 exits for servos/actuators
