Appendix 2 - Flash codes Dual Receiver 12-22 R series
2.1 Flash codes Dual Receiver 12-22 R series
Flash codes on switch board:
Status - green LED:
Flash code: Function:
- Switch on (0,5 s on) Function test
- Blinking (
0,5 s on – 0,5 s off) Binding
- Double blinking (0,2 s on – 0,1 off – 0,2 s on - 0,5 s off) Threshold value reception
- 3 times blinking (0,2 s on – 0,1 off – 0,2 s on - 0,1 s off –
0,2 s on - 0,5 s off)
Threshold value temperature
- Fast blinking (0,25 s on – 0,25 s off) Calibration gyro (max.10 s)
- Steady green with short interruption (0,9 s on - 0,1 s off) Reception + GPS reception
- Steady green (on) Data reception
2.2 Flash codes Dual Receiver 12-22 R series
Flash codes on switch board:
Battery – red LED:
Flash code: Function:
- Switch on (0,5 s on) Function test
- Hektic blinking (0,2 s on – 0,1 off) Bad battery
- Double blinking (0,2 s on – 0,1 off – 0,2 s on - 0,5 s off) Threshold value battery voltage
- Fast blinking (0,25 s on – 0,25 off) Backup battery was used
- Blinking (0,5 s on – 0,5 s off) Normal operation with main battery
2.3 Flash codes Dual Receiver 12-22 R series
Flash codes on case:
Log – yellow LED: (only on case)
Flash code: Function:
- Blinking (0,5 s on – 0,5 s off) Logging on SD card
- Fast blinking max 10 s (0,25 s on – 0,25 s off) Calibration of internal gyros
- Fast blinking (0,25 s on – 0,25 s off) Mistake – no calibration of gyros
