Mazda 3 MPS
1311472A
23
b = 450mm
c = 660mm
Dispose of section X
Cut the braided protective hose into sections
and slide it onto hose B and hose C.
Cutting
water
hoses into
sections
Cut the braided protective hose in the middle
and slide it onto hose B and hose C.
Cut shrink-fit hose to size.
1 25 mm shrink-fit hose [4x]
2 Black (sw) rubber profile
Preparing
the water
hoses
Turn the original vehicle clamp 1 down.
Remove the hose coating 3 from the engine
exhaust hose 2.
1 Turn the original vehicle clamp up.
Preparing
the
splitting
point
B
X X
b c
C
A
B
C
1 1
1 1
150
2
45
1
46
1 2
3
60mm
