Webasto Mazda 3 MPS - Page 24

Mazda 3 MPS
1311472A
24
1 Original vehicle engine exhaust hose
2 Cut location
Splitting
point
1
Engine exhaust hose section
Connec-
tion of
moulded
hose A:
1
Heater unit
Connect-
ing hose B
on the
heater unit
Align the rubber profile 1.
Connect-
ing hose B
to moulded
hose A
47
1
2
48
A1
49
B
1
50
B
A
1
