Webasto Mazda 3 MPS - Page 25

Mazda 3 MPS
1311472A
25
1 Heater unit
2 Cable clips
Connect-
ing hose C
on the
heater unit
Before connecting, fill the water hoses with
coolant.
Insert the hose bracket
1 as shown in the
figure.
2 Heat exchanger inlet hose section
Connect-
ing to the
heat
exchanger
inlet
Prepare the water hoses with cable clips 1
according to the figure.
Hose
placement
51
C 1
2
52
C
1
2
B
53
B
1
1 C
