4.3 Physical Installation
The SVS-300 weighs 260 kg. Always use appropriate equipment for
handling the unit. Use a forklift of sufficient capacity to lift the unit.
Do not use hooks to lift the unit.
Do not tip the unit. It must be kept in vertical position.
The external dimensions of the SVS-300 are:
- Base: 51,9 x 62,3 cm (20.44 x 24.50 in)
- Height: 105,7 cm (41.63 in)
Location
Choose your installation location to:
Avoid temperature and humidity extremes.
Minimize moisture and dust.
Provide adequate air circulation to prevent the buildup of fumes.
Install on a cement pad minimum 7” above surrounding curbing or walkways for water flood
control, see Figure 4- 1
Maintain a minimum of 18” of clearance on the sides of the unit for proper ventilation.
Maintain 36” minimum clearance on Front and Back for servicing as required by local codes.
Do not install unit where it will be exposed to direct sunlight.
