SVS-200 Installation, Operation and Maintenance
IMPORTANT INFORMATION – SAVE THESE INSTRUCTIONS
20153-W-03-01 15 Webasto Charging Systems, Inc.
Table 5- 1 LED Labels and Meanings
LED Label
Color
When Steady Lit
When Flashing
Equalizing
green
Battery undergoing equalization
Equalization scheduled
Charge Complete
green
Charge Complete and stopped
N/A
80% Charged
green
The Battery SOC is >= 80%
N/A
Charging
amber
Battery connected and charging
N/A
Fault/Warning
red
Fault (charge stopped)
Warning (check log)
Step 2: Stop Charging
Once the battery has been fast-charged to the SOC preset in the BMID or Charger, the SVS-
300 will stop the charge and illuminate the “Charge Complete” LED. If an equalization charge
is scheduled for this battery pack, the Charge Complete will not illuminate until the
equalization has been completed. The operator may stop charging at any time without waiting
for the charge to complete, by pressing the "STOP" button or disconnecting the battery cables
from the charger.
After a charge has been completed or stopped by the user, the screen will indicate the method
in which the charge was stopped and the data values just before the end of charging will be
displayed (see Figure 5- 4).
Figure 5- 4 Charge Complete Screens
Step 3: Disconnect battery cables from charger
NOTE: If the operator disconnects the cables without pressing STOP, the charger will
immediately stop charging and prevent any arcing.
Chg Complete 100%
62.0V 0 A 23C
Chg Stopped 62%
51.8V 0 A 10C
Or
