5.10.2.2 External Lights 1, 2 and 3
 Press <enter> to display the Light 1 setting. Figure 5- 13)
 Press <enter> again to select from the 5 Charger states of operation.
 Use the <up> and <down> buttons to choose the charger state you wish to monitor.
 Once the desired state is displayed, press <enter> to store the edited value.
 Press <clear> to exit.
5.10.3 EQ Button Action
The EQ Button Action menu is used to configure the actions of the front panel EQ button. The
three valid configurations are:
1. ALWAYS_ACTIVE – The EQ button is always active.
2. DISABLED – The EQ button is disabled.
3. WORKS_ON_EQ_DAY_ONLY – The EQ button works on scheduled EQ day only.
Figure 5- 14 EQ Button Action
5.10.3.1 Setting the EQ Button Action
From the “EQ Button Action” screen, press <enter> to display the current EQ button configuration.
Press <enter> again and the programmable parameter will flash. Use the <up> and <down>
buttons to toggle parameters. The display will continue to flash until you press <enter> to set the
displayed parameter. Press <clear> to exit.
DISABLED - This setting causes the charger to ignore the EQ button.
ALWAYS ACTIVE - This is the default setting and causes the EQ button to be active at all times.
WORKS ON EQ DAY ONLY - This setting causes the EQ button to function only on the day of the
week programmed in the BMID for equalization.
EQ Button Action:
Disabled
EQ Button Action:
WORKS ON EQ DAY ONLY
EQ Button Action:
Always Active
EQ Button Action
Configuration
CLEAR
ENTER
ENTER
CLEAR
Charger Configuration
Press ENTER to accept the selection made.
After pressing ENTER, press CLEAR to retain
the original value.
ENTER
