6 Maintenance
6.1 General Maintenance
CAUTION
Always disconnect and lockout/tagout power to the unit before performing
any maintenance.
Under most conditions, the SVS-300 requires very little maintenance.
 The air inlet must be kept free from debris. Blow out or vacuum out dust accumulation
periodically.
 As needed, repair or replace damaged or worn output cables and connectors.
All other servicing is to be performed by Authorized service personnel only.
Replacing DC Output Power Cables
Replacement cables may be purchased directly from your Authorized SVS-300 dealer.
Figure 6- 1 DC Output connections
N WARNING
Use only connectors and cable that are rated for the full continuous
current rating of the unit unless the output current of the unit has been
adjusted to a lower value.
Minimum Bend
Radii 3.5 in
