Webasto SVS300 User Manual

SVS-200 Installation, Operation and Maintenance
IMPORTANT INFORMATION – SAVE THESE INSTRUCTIONS
20153-W-03-01 30 Webasto Charging Systems, Inc.
5.10.4 Auto EQ
Figure 5- 15 Auto EQ Menu
5.10.5 Fast Charge SOC Limit
The charger can be configured to allow fast charging of batteries only up to a fixed percentage.
This percentage of battery state of charge is calculated when the battery is first connected to the
charger and is updated as the charging progresses. If a battery is charged up to this limit and is
not scheduled to full charge or equalize, the charging is stopped. If the charger is configured for
full charging or equalizing during this period, charging will proceed past this SOC limit as the
charger enters the full charge or equalization state.
This fast charge limit is also used in conjunction with the BMID programmed fast charge limit.
The lower of these two parameters are used to terminate a fast charge session. This parameter
can be set to 100% to allow only the BMID SOC limit to be the limiting point. If backup battery (or
ultra-cap) power is lost, this parameter will need to be review and/or updated, as it will be set to a
default value in this case.
Figure 5- 16 Fast Charge SOC Limit Screens
Auto EQ:
ON
ENTER
Auto EQ:
OFF
Press ENTER to accept the selection made.
Press CLEAR to retain the original value.
CLEAR
Charger Configuration
Fast Charge SOC
Limit
ENTER
Fast Chrg SOC Limit:
100%
Use the UP and DOWN arrow buttons to set the parameter to the appropriate value.
Press ENTER again to accept the selection made.
Press CLEAR to retain the original value
CLEAR
Charger Configuration
