Webasto Thermo Top C Installation Documentation

11
Peugeot 207 / 207 SW / 207 CC
Wiring dia-
gram for
manual air
condition-
ing
Webasto components Vehicle components Colours and symbols
Legend
HG TT-C/E Heater 8050 Fan motor rt red
X1 6-pin connector 8025 Fan switch/A/C control
panel
ws white
F3 25 A fuse sw black
K3 Fan relay 8046 Resistor group br brown
K3.1 Additional relay PSF1 Main power supply gn green
IC26 6-pin connector vi violet
2V NR 2-pin connector
4V NR 4-pin connector
8V NR 8-pin connector
X Cutting point
Wiring colours may vary.
gn/
ws
ws
sw
rt/ws
rt
Webasto
31
30
15
Peugeot
ws
rt
F3
PSF 1
F11
R7
2
2V NR
3
IC26
2V NR
1 2
8050
M
86
85 30
87a87
K3
HG
X1
4
86
85 30
87a87
K3.1
rt
1,5²
br
1,5²
br
4²
sw
4²
sw
4²
sw
4²
vi
1²
vi
1²
br
1,5²
5
3
1
4
2
8046
3241
4V NR
8025
8V NR
6 7 5 4 3 1
i
