Webasto Thermo Top C Installation Documentation

22
Peugeot 207 / 207 SW / 207 CC
KFU/NFU
a = 640 mm
b = 530mm
Discard section
X
Cutting
hoses to
length
1
Cutting point
Cutting
point
1
Black (sw) rubber profile fastened on trans-
mission mount with cable tie
2 Engine outlet hose section
Connect-
ing engine
outlet
Install coolant hose A with straight end on
heater inlet.
Connect-
ing heater
ab
A B
X
X
1
35
36
1 2
A
37
A
