Webasto Thermo Top C Installation Documentation

24
Peugeot 207 / 207 SW / 207 CC
5FW/X/Y
a = 640 mm
b = 530mm
Discard section
X
Cutting
hoses to
length
1
Cutting point
Cutting
point
1
Engine outlet hose section
2 Black (sw) rubber profile fastened on trans-
mission mount with cable tie
Connect-
ing engine
outlet
Install coolant hose A with straight end on
heater inlet.
Connect-
ing heater
ab
A B
X
X
41
1
42
1
2
A
43
A
