Webasto Thermo Top C Installation Documentation

27
Peugeot 207 / 207 SW / 207 CC
b = 480 mm
c = 390 mm
Discard section
X
Cutting
hoses to
length
Disconnect coolant hose 1 from engine out-
let. Hose clamp will be reused.
Cutting
point
1
Original vehicle hose clamp
Connect-
ing engine
outlet
Install coolant hose B with straight end on
heater inlet.
Connect-
ing heater
cb
C
X
X
B
1
47
48
1
B
A
49
B
