Webasto Thermo Top C Installation Documentation

34
Peugeot 207 / 207 SW / 207 CC
Diesel
1
Exhaust pipe
a =170mm
2 Exhaust end section
b = 100mm
Discard section
X
Preparing
exhaust
pipe
1
Silencer
2 M6x55 bolt, flanged nut
3 40 mm spacer
Mounting
exhaust
end sec-
tion
Ensure sufficient distance from neighbouring
components.
1 Hose clamp [3x]
2 Exhaust pipe
3 Exhaust end section
Position-
ing rubber
isolator
a b
1 2
X
1
2
3
68
2
1 1 1
3
69
