6
CR 2 CR 2/55
Weight
Operating weight CECE [kg] 156 164
Dimensions
Overall length [mm] 1215 1215
Overall width/with attachment plates [mm]
450 550
Height with folded guide bar [mm] 1065 1065
Base plate length [base in mm] 200 200
Pressure surface [mm] 200x450 500x450
Drive
Engine manufacturer Hatz Hatz
Type 1 B 20 1 B 20
Performance at operating speed in
accordance with ISO 3046-1 [kW] 3.1 3.1
Combustion process 4-stroke diesel 4-stroke diesel
Operating speed [1/min] 3000 3000
Operating speed [soil-dependent, m/min] 21 21
Incline capacity [soil-dependent, %] 35 35
Vibration
System Two-shaft vibrator Two-shaft vibrator
Drive concept mechanical mechanical
Frequency [Hz] 100 100
Centrifugal force [kN] 25 25
Noise emissions in accordance
with 2000/14/EC
Sound pressure level LPA ascertained
in accordance with EN 500, [dB (A)] 98 98
Sound power level LWA ascertained
in accordance with EN ISO 3744
and EN 500, [dB (A)] 108 108
Vibration values
Root-mean-square acceleration value
for hand-arm vibration ascertained in
accordance with EN 500, [m/s²] 3.6 3.6
In accordance with directive 2006/24/EC,
complying with the vibration values is
the owner’s responsibility
3. Technical data
