WEG CFW501 V1.8X User Manual

V VW Vector Control
10-6 | CFW501
10
P0401 – Motor Rated Current
Adjustable
Range:
0 to 200.0 A Factory
Setting:
1.0 x I
nom
Properties: cfg
Access groups
via HMI:
MOTOR, STARTUP
P0402 – Motor Rated Speed
Adjustable
Range:
0 to 30000 rpm Factory
Setting:
1710 rpm
(1425 rpm)
Properties: cfg
Access groups
via HMI:
MOTOR, STARTUP
P0403 – Motor Rated Frequency
Adjustable
Range:
0 to 500 Hz Factory
Setting:
60 Hz (50 Hz)
Properties: cfg
Access groups
via HMI:
MOTOR, STARTUP
P0404 – Motor Rated Power
Adjustable
Range:
0 = 0.16 hp (0.12 kW)
1 = 0.25 hp (0.19 kW)
2 = 0.33 hp (0.25 kW)
3 = 0.50 hp (0.37 kW)
4 = 0.75 hp (0.55 kW)
5 = 1.00 hp (0.75 kW)
6 = 1.50 hp (1.10 kW)
7 = 2.00 hp (1.50 kW)
8 = 3.00 hp (2.20 kW)
9 = 4.00 hp (3.00 kW)
10 = 5.00 hp (3.70 kW)
11 = 5.50 hp (4.00 kW)
12 = 6.00 hp (4.50 kW)
13 = 7.50 hp (5.50 kW)
14 = 10.00 hp (7.50 kW)
15 = 12.50 hp (9.00 kW)
16 = 15.00 hp (11.00 kW)
17 = 20.00 hp (15.00 kW)
18 = 25.00 hp (18.50 kW)
19 = 30.00 hp (22.00 kW)
Factory
Setting:
According
to inverter
model
Properties: cfg
Access groups
via HMI:
MOTOR, STARTUP
