V VW Vector Control
CFW501 | 10-5
10
Set it according to the value informed on the motor nameplate.
It affects the motor overload protection.
P0399 – Motor Rated Efficiency
Adjustable
Range:
50.0 to 99.9 % Factory
Setting:
75.0 %
Properties: cfg, V V W
Access groups
via HMI:
MOTOR, STARTUP
Description:
This parameter is important for the precise operation of the VVW control. The imprecise setting will cause the
incorrect calculation of the slip compensation and consequent speed control imprecision.
P0400 – Motor Rated Voltage
Adjustable
Range:
200 to 600 V Factory
Setting:
According to Table
10.2: Default setting
of P0400 according
to the identified
inverter model on
page 10-5
Properties: cfg
Access groups
via HMI:
MOTOR, STARTUP
Description:
Set according to the data on the motor nameplate and the wire connection on the motor terminal box. This
value cannot be above the rated voltage value set in P0296 (power supply rated voltage).
NOTE!
In order to validate a new setting of P0400 out of the HMI “STARTUP” menu, it's necessary to power
cycle the inverter.
Table 10.2: Default setting of P0400 according to the identified inverter model
P0296 P0145 (Hz) P0400 (V)
0
50.0 230
60.0 220
1
50.0 400
60.0 380
2
50.0 525
60.0 575
For further information on model identification, refer to Table 6.2: Identification of the CFW501 models for
frames A, B, C, D and E on page 6-2.
