Weider 146 Bench User Manual

13
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
1 1 Right Upright
2 1 Frame
3 1 Crossbar
4 1 Leg Lever
5 2 Backrest Tube
6 1 Backrest
7 1 Support Tube
8 1 Front Leg
9 1 M10 x 130mm Bolt
10 2 Short Pad Tube
11 1 Seat
12 2 Handgrip
13 8 25.4mm Square Inner Cap
14 6 19mm Round Inner Cap
15 2 38mm Square Inner Cap
16 1 Left Upright
17 4 25.4mm Round Inner Cap
18 2 50mm Square Bushing
19 2 Weight Rest
20 18 M8 Washer
21 6 M10 Nylon Locknut
22 4 M10 Washer
23 3 M8 x 16mm Screw
24 2 Dip Handle
25 8 M8 x 40mm Screw
26 5 M10 x 70mm Bolt
27 2 M8 x 55mm Bolt
28 1 Right Barbell Hook
29 1 Curl Upright
30 1 Left Barbell Hook
31 1 Small Threaded Knob
32 2 Large Threaded Knob
33 7 M8 Nylon Locknut
34 6 Foam Pad
35 1 Long Pad Tube
36 1 Leg Lever Lock
37 2 M8 x 60mm Bolt
38 2 11mm x 10.5mm Spacer
39 1 M8 x 51mm Bolt
40 2 Support Plate
41 1 Curl Pad
42 2 M6 x 16mm Screw
# 1 User’s Manual
# 1 Exercise Poster
Key No. Qty. Description Key No. Qty. Description
Part List - Model No. WECCBE04500
R0803A

Weider 146 Bench Specifications

General

Brand	Weider
Model	146 Bench
Category	Home Gym
Language	English
