5
Part Identification Chart
R0402A
M10 x 130mm Bolt (9)
—1
M10 x 70mm Bolt (26)—5
M8 x 40mm Screw (25)—8
M8 x 16mm Screw (23)—3
M10 Washer (22)—4
M8 Nylon Locknut (33)—7
M8 Washer (20)—18
M10 Nylon Locknut (21)—6
M8 x 60mm Bolt (37)—2
M8 x 55mm Bolt (27)—2
M8 x 51mm Bolt (39)—1
11mm x 10.5mm Spacer (38)–2
M6 x 16mm Screw (42)—2
