M6 Washer (80)
M8 Washer (59)
M4 Washer
(33)
M10 x 70mm Bolt (72)
M10 x 46mm Bolt (81)
M10 x 63mm Bolt (75)
M10 x 67mm Bolt (71)
M10 x 85mm Bolt (67)
M10 x 25mm Button Screw (77)
M10 x 155mm Bolt (74)
M8 x 65mm Bolt (68)
M8 x 22mm Shoulder Bolt (65)
M6 x 63mm Screw (70)
M6 x 16mm Screw (62)
M4 x 20mm Self-tapping Screw (69)
M10 x 77mm Bolt (79)
M10 x 51mm Bolt (66)
M8 x 63mm Carriage Bolt (64)
M10 Washer (57)
M12 Nut (82)
Large Washer (78)
M10 Locknut (56)
M8 Locknut (58)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. Note: If a part is not in the
hardware kit, check to see if it has been preattached.
To Next Page
